RIGOL MSO5074 Lab Oscilloscope 350MHz Bandwidth with Upgrade Options

Description

Product Overview

The RIGOL MSO5074 is a versatile laboratory oscilloscope designed for engineers who need accurate, high‑speed signal analysis. It features a native 350 MHz analog bandwidth, with upgrade paths to 200 MHz, 100 MHz, or 70 MHz, allowing you to tailor performance to your application. The instrument supports 2 or 4 analog channels (expandable) and includes 16 digital channels when paired with a logic analyzer probe. With a real‑time sample rate of up to 8 GSa/s and optional memory depth of 200 Mpts, the MSO5074 captures fast transients and long records with ease. Its compact chassis measures 5.12 × 14.45 × 7.87 inches and weighs 7.7 lb, making it portable enough for field work while still offering a robust, corded‑electric power source for continuous operation.

Usage

Designed for both laboratory benches and on‑site diagnostics, the MSO5074 excels in electronics development, automotive testing, and industrial equipment maintenance. Its high waveform capture rate—over 500,000 waveforms per second—ensures you never miss critical events during fast‑changing measurements. Whether you are debugging a PCB, validating a power supply, or analyzing communication protocols, the oscilloscope’s flexible channel configuration and deep memory provide the clarity needed for precise troubleshooting.

Why Choose Us

RIGOL’s reputation for reliable, cost‑effective test equipment backs the MSO5074. Each unit undergoes rigorous quality testing and comes with a comprehensive warranty and responsive technical support. The modular upgrade options protect your investment, allowing you to expand bandwidth or add channels without replacing the entire instrument. This long‑term value, combined with intuitive software and a user‑friendly interface, makes the MSO5074 a smart choice for professionals seeking performance without compromise.

Key Features

• High 350 MHz bandwidth captures detailed signal nuances for accurate analysis.
• Up to 8 GSa/s real‑time sampling ensures fast transients are recorded without distortion.
• Expandable analog channels and 16 digital inputs provide flexible measurement configurations.
• Deep 200 Mpts memory depth allows long‑duration captures for complex waveform analysis.
• Dedicated RIGOL support team offers prompt assistance and firmware updates.

FAQ

Can the bandwidth be upgraded after purchase?

Yes, the MSO5074 supports optional bandwidth upgrades to 200 MHz, 100 MHz, or 70 MHz through a simple hardware module.

How many analog channels can I use?

The base model includes 2 analog channels, which can be expanded to 4 with an additional module.

What is the maximum memory depth?

With the optional memory upgrade, the oscilloscope can achieve up to 200 Mpts of record length.

Is a logic analyzer probe required for digital channels?

Yes, the 16 digital channels are accessible when a compatible RIGOL logic analyzer probe is connected.

What warranty does RIGOL provide?

The MSO5074 comes with a standard one‑year limited warranty covering parts and labor, with extended service plans available.
